★Note: To use the Parts Diagram simply hover over the number associated with the part you are interested in and click it to navigate to the part's detail page.★
| Number | Sku | Image | Name |
|---|
| 1 | 86222230 |  |
Molded Cargo Net, NuWave |
| 2 | 86292430 |  |
Fastener Tree Clip, NuWave |
| 3 | 86297590 |  |
Screw, M8 x 25, NuWave |
| 4 | 86218940 |  |
Body Hinge, NuWave |
| 5 | 86291240 |  |
Extruded Glide Rail, NuWave |
| 6 | 86215900 |  |
Body/Hinge Mount Bracket, NuWave |
| 7 | 86137280 |  |
87054 - Washer M8 Flat 125A PLT, Windsor Lightning 1500 & 2000 |
| 8 | 86279130 |  |
87083 - Washer, 5/16 Split Lock PLTD |
| 9 | 86274860 |  |
70311 - Screw, M8 x 20, NuWave |
| 10 | 86225610 |  |
Vacuum Body Trim, NuWave |
| 11 | 86295940 |  |
Rotomold Clip Bracket, NuWave |
| 12 | 86223680 |  |
70700 - Screw, M5X.8X10 PHMS BLK, Windsor Lightning 1500 |
| 13 | 86369510 |  |
Screw, KA50x13, NuWave |
| 14 | 86303870 |  |
Screw, M8 x 20, NuWave |
